| Marvell Chipset | 98DX223S/ 98DX226S |
| FLASH | 128 Mb |
| RAM | 512 Mb |
| FANs | NA |
| LED Indicators | PWR, SYS, Link/ACT LED |
| Power Interface | 220V/AC interface (external power supply) |
| Input Voltage | AC 100-240V 50/60Hz |
| Total Power Consumption | Non PoE full load ≤ 10W |
| POE budget | 240W |
| Operating Temperature | PoE: -30℃~+50℃; Non PoE: -30℃+60℃ |
| Thermal Methods | Fan-less design, natural heat dissipation |
| MTBF | 100,000h |
| Case | 152*115*44mm (L*W*H) |
| Weight | 0.6KG |
| Copper ports 1Gb/s | 8x1Gbps |
| SFP/SFP+ | 4 |
| Other Ports | Console, OOB, USB 2.0, Fact Reset |
