| Chipset | 98DX226S |
| FLASH | 128 Mb |
| RAM | 512 Mb |
| Switching Capacity | 68G |
| Packet Forwarding Rate | 50.59Mpps |
| MTBF | 100,000 hours |
| PoE budget | 240W |
| POE++ ports | 16xPOE+ |
| Dimensions (WxDxH, mm) | 48mm X 143mm X 104mm |
| Weight | 1.2 Kg |
| LED Indicators | PWR, Link/ACT LED |
| Input voltage | Non-PoE DC12-58V; PoE DC48-58V |
| Power consumption | Non-PoE<26W; PoE <266W |
| Heat dissipation | Natural heat dissipation |
| Copper Downlink ports 1Gb/s | 16 |
| SFP/SFP+ | 2 |
| Other Ports | Console, USB2.0 |
| Power Interface | Phoenix terminal, redundant dual power supply |
